The TCM4 Dash Cam is a comprehensive 4-camera surveillance system, consisting of one main unit camera and three external cameras. All there lenses record in full 1080p HD clarity for detailed footage. Its core features include real-time GPS location tracking and live streaming capability, enabling remote monitoring from anywhere.
Designed for versatility, it is an ideal safety solution for large vehicles like trucks and buses, providing extensive coverage. Furthermore, its flexible setup allows it to function effectively as a reliable home security system, offering peace of mind in various scenarios.
Product Advantage
1. The TCM4 dash cam system offers comprehensive monitoring through its quad-camera setup, including one main unit and three external lenses. The main cameras support up to 1080p resolution, capturing clear footage of critical details such as license plates and road signs. This design is particularly effective for enhancing visibility around large vehicles like trucks and buses, while also serving as a versatile multi-angle security camera for other applications. As a dashcam front rear gps solution, it provides broad situational awareness without the complexity of full 360° systems.
2. Real-Time Fleet Management with Live Video & GPS
Elevate your operations with true Live Video GPS dashcam capabilities. The TCM4 combines real-time GPS tracking with instant live streaming. Managers can view any camera feed remotely via an app, verifying incidents as they happen and monitoring driver behavior and vehicle location simultaneously. This transforms the device into a powerful GPS Fleet Manager, enabling proactive decision-making, enhanced security, and optimized routing—all from a central dashboard.
3. Proactive Safety Alerts with Built-in 1-Way ADAS
Go beyond recording and enhance driver safety with the integrated 1-way ADAS (Advanced Driver Assistance System). This intelligent feature uses the high-resolution 1080p/720p camera to analyze the road ahead. It provides timely audio and visual alerts for potential hazards like Lane Departure Warnings (LDW) and Forward Collision Warnings (FCW). This proactive technology helps prevent accidents before they occur, making it an invaluable dashcam gps combo for promoting safer driving habits.
4. Seamless Connectivity & Cross-Platform Control
Experience effortless operation with the TCM4's integrated Wi-Fi and universal app compatibility. Designed for everyone, it works flawlessly with both android gps dashcam and ios gps dashcam applications. The user-friendly app allows for easy live view, video playback, settings adjustment, and instant download of important footage directly to your smartphone. This WiFi GPS Dual Dash Cam design ensures you are always connected and in full control, no matter your device.
Technical Parameters
project | Equipment | Performance index |
system | operating system | Embedded linux operating system |
operating language | Chinese/English | |
Operating interface | Configuration through Simba Maintenance APP 3.0 | |
Password security | User password management | |
audio and | Video system | pal/ntsc |
Compression | h.265/h.264 | |
image resolution | 720p/960h/d1/cif(support 2ch 1080p) | |
Playback quality | 720p/960h/d1/cif | |
compound mode | 4-way flexible configuration | |
Decoding ability | 4-way 720p real-time | |
Video quality | Level 1 to 6 can be matched. | |
Screen display | Support 1,2,3,4 screen display. | |
audio compression | g.711a、g.711u、g.726 | |
Recording mode | Synchronous recording of sound and video | |
Video | Video recording | Automatic,alarm |
Audio code rate | 8kb/s | |
Video inquiry | It can be searched by channel and video type. | |
Local playback | Multiplex playback | |
software | Upgrade mode | Manual upgrade,automatic upgrade,remote upgrade |
Upgrade method | U disk,tf card,wireless network | |
joggle/inter | Audio and video | 3-way 4pin BMW head interface;Built-in high sensitivity |
face | input | microphone |
audio output | Built-in 1.5w speaker | |
Alarm input | 3 channels of input(positive/negative trigger can be | |
Alam output | One output can directly drive the relay(<150ma). | |
Tf card | 2tf card interfaces | |
Usb interface | 1 micro usb interface | |
Ignition input | 1 acc signal | |
light emitting diode | Pwr/run two-color lamp | |
Sd card lock | one | |
rs232 | 1 rs232 interface(debug function) | |
rs485 | 1 rs485 interface | |
Sim interface | 1 micro sim interface | |
extended | gps | Internal ceramic antenna,gps+bd |
wireless | Support 4g full netcom | |
wifi | Frequency 2.4ghz | |
other | Power input | dc:8v~36v |
Camera loading | 1a/1v | |
Typical power | 10w(excluding peripherals) | |
Working | -20---70℃ | |
storage capacity | 720p 270mb/hour/channel h.265 | |
measure | 111.38*87.3*27mm |
Product Uses
1. Comprehensive Fleet Management
Ideal for logistics and transport companies, it enables real-time GPS tracking and live driver monitoring via its multi-camera system, enhancing fleet safety and operational efficiency as a complete GPS Fleet Manager solution.
2. Commercial Vehicle Security
Perfect for trucks, buses, and delivery vans, its dashcam front rear gps setup provides 360° coverage to monitor cargo, prevent theft, and document incidents with dashcam full hd gps clarity.
3. Professional Driver Safety & Training
The built-in 1-way ADAS promotes safer driving with collision warnings, while recorded footage serves as valuable material for driver coaching and accident analysis.
4. Versatile Property & Home Surveillance
Beyond vehicles, its dashcam with live streaming capability allows it to function as a reliable, multi-angle security camera for monitoring warehouses, shops, or residential properties remotely.
5. Ride-Sharing & Personal Vehicle Protection
Provides essential evidence and security for ride-share drivers and personal car owners, with features like impact detection and live streaming to ensure safety and resolve disputes.
FAQ
Q1. Can you do hardware/software customization?
A: Yes, we offer not only OEM but ODM services, include online tracking platform.Our professional technician would also provide more after-sales service 7/24 hours
Q2. Does this GPS tracker need a sim card?
A:Yes.
Q3. How long will I get the goods after the payment?
A: This depends on quantity and logistics system. In normal condition, the goods will arrive at your address in 7-30 days. More details, please contact our sales for confirming.
Q4. Do you accept rebrand &logo custom?
A: Yes, rebrand on product case or product itself is available.
Q5. How are your quality control?
A: All products have been 100% strictly quality checked in the house before packing.
